#include <MemoryStateOperations.hpp>

Inheritance diagram for jlm::llvm::CallEntryMemoryStateMergeOperation:

[legend]

Collaboration diagram for jlm::llvm::CallEntryMemoryStateMergeOperation:

[legend]

Public Member Functions
	~CallEntryMemoryStateMergeOperation () noexcept override

	CallEntryMemoryStateMergeOperation (const std::vector< MemoryNodeId > &memoryNodeIds)

bool	operator== (const Operation &other) const noexcept override

std::string	debug_string () const override

std::unique_ptr< Operation >	copy () const override

std::vector< MemoryNodeId >	getMemoryNodeIds () const noexcept

Public Member Functions inherited from jlm::rvsdg::SimpleOperation
	~SimpleOperation () noexcept override

	SimpleOperation (std::vector< std::shared_ptr< const jlm::rvsdg::Type >> operands, std::vector< std::shared_ptr< const jlm::rvsdg::Type >> results)

size_t	narguments () const noexcept

const std::shared_ptr< const rvsdg::Type > &	argument (size_t index) const noexcept

size_t	nresults () const noexcept

const std::shared_ptr< const rvsdg::Type > &	result (size_t index) const noexcept

Public Member Functions inherited from jlm::rvsdg::Operation
virtual	~Operation () noexcept

virtual bool	operator== (const Operation &other) const noexcept=0

bool	operator!= (const Operation &other) const noexcept

Static Public Member Functions
static rvsdg::Input *	tryMapMemoryNodeIdToInput (const rvsdg::SimpleNode &node, MemoryNodeId memoryNodeId)

static rvsdg::SimpleNode &	CreateNode (rvsdg::Region &region, const std::vector< rvsdg::Output * > &operands, std::vector< MemoryNodeId > memoryNodeIds)

Private Attributes
util::BijectiveMap< MemoryNodeId, size_t >	MemoryNodeIdToIndex_ {}

Additional Inherited Members
Protected Member Functions inherited from jlm::llvm::MemoryStateOperation
	MemoryStateOperation (size_t numOperands, size_t numResults)

Detailed Description

A call entry memory state merge operation takes multiple states as input and merges them together to a single output state. In contrast to the MemoryStateMergeOperation, this operation is allowed to have zero input states. The operation's output is required to be connected to the memory state argument of a call.

The operation has no equivalent LLVM instruction.

See also: CallExitMemoryStateSplitOperation

Definition at line 509 of file MemoryStateOperations.hpp.

Constructor & Destructor Documentation

◆ ~CallEntryMemoryStateMergeOperation()

jlm::llvm::CallEntryMemoryStateMergeOperation::~CallEntryMemoryStateMergeOperation ( )

overridedefaultnoexcept

◆ CallEntryMemoryStateMergeOperation()

jlm::llvm::CallEntryMemoryStateMergeOperation::CallEntryMemoryStateMergeOperation ( const std::vector< MemoryNodeId > & memoryNodeIds )

explicit

Definition at line 603 of file MemoryStateOperations.cpp.

Member Function Documentation

◆ copy()

std::unique_ptr< rvsdg::Operation > jlm::llvm::CallEntryMemoryStateMergeOperation::copy ( ) const

overridevirtual

Implements jlm::rvsdg::Operation.

Definition at line 628 of file MemoryStateOperations.cpp.

◆ CreateNode()

static rvsdg::SimpleNode& jlm::llvm::CallEntryMemoryStateMergeOperation::CreateNode	(	rvsdg::Region &	region,
		const std::vector< rvsdg::Output * > &	operands,
		std::vector< MemoryNodeId >	memoryNodeIds
	)

inlinestatic

Definition at line 553 of file MemoryStateOperations.hpp.

◆ debug_string()

std::string jlm::llvm::CallEntryMemoryStateMergeOperation::debug_string ( ) const

overridevirtual

Implements jlm::rvsdg::Operation.

Definition at line 622 of file MemoryStateOperations.cpp.

◆ getMemoryNodeIds()

std::vector<MemoryNodeId> jlm::llvm::CallEntryMemoryStateMergeOperation::getMemoryNodeIds ( ) const

inlinenoexcept

Returns: The MemoryNodeId for each of the operation's results.

Definition at line 529 of file MemoryStateOperations.hpp.

◆ operator==()

bool jlm::llvm::CallEntryMemoryStateMergeOperation::operator== ( const Operation & other ) const

overridenoexcept

Definition at line 615 of file MemoryStateOperations.cpp.

◆ tryMapMemoryNodeIdToInput()

rvsdg::Input * jlm::llvm::CallEntryMemoryStateMergeOperation::tryMapMemoryNodeIdToInput	(	const rvsdg::SimpleNode &	node,
		MemoryNodeId	memoryNodeId
	)

static

Maps a memory node identifier to the respective input of a CallEntryMemoryStateMergeOperation node.

Parameters

node	A CallEntryMemoryStateMergeOperation node.
memoryNodeId	A memory node identifier.

Returns: The respective input if the memory node identifier maps to one, otherwise nullptr.

Definition at line 634 of file MemoryStateOperations.cpp.

Member Data Documentation

◆ MemoryNodeIdToIndex_

util::BijectiveMap<MemoryNodeId, size_t> jlm::llvm::CallEntryMemoryStateMergeOperation::MemoryNodeIdToIndex_ {}

private

Definition at line 567 of file MemoryStateOperations.hpp.

The documentation for this class was generated from the following files:

jlm/llvm/ir/operators/MemoryStateOperations.hpp
jlm/llvm/ir/operators/MemoryStateOperations.cpp
